Fully hydraulic crawler remote control composter

    Self Propelled Compost Turner M30A has been precisely adapted to this windrow width. With a turning capacity of more than 800 m3/hour and a windrow cross- -section of up to 3.5 m3/running meter, even performance freaks will get their money's worth with this compost turner.

    Processing Capacity: 600 m³

    Width: 2.6m

    Engine Power: 55KW

    Fuel Tank Capacity: 40L

    Application scenarios:

    Farm, Ranches, Organic fertilizer factory, individual farm land


SHARE:

Product Detiles

Overview of Self Propelled Compost Turner M30A

Self Propelled Compost Turner M30A represents the ideal solution for ensuring perfect aerobic rotting conditions. As compost windrows with a width of up to 3m have particularly good properties for the production of high-quality compost products, M30A has been precisely adapted to this windrow width. With a turning capacity of more than 800 m³/hour and a windrow cross-section of up to 3.5 m3/running meter, even performance freaks will get their money's worth with this compost turner.

compositemachine

Features of Self Propelled Compost Turner M30A


1. Composting machine with compact design, small space occupation and flexible use

2. High-end diesel engine with stable performance and low energy consumption

3. Adjustable rotor height

4. Fully hydraulic drive, low maintenance cost

5. Self-propelled composting turner, no tractor needed-best space utilization

6. Easy to transport and can be used anytime and anywhere

7. The production capacity is about 600 cubic meters per hour

Applications of Self Propelled Compost Turner M30A

The main function of a self-propelled compost turner is to turn waste into fertilizer by fermenting the mix. The key component to producing high-quality fertilizer is adding microbial strains and oxygen to animal manure and other solid waste. This method prevents poisonous gasses from accumulating and meets the requirements of the Environmental Protection Act.

Using a self-propelled windrow turner, you can lower the temperature of the compost and fill the mix with oxygen. Original pollutants turn into organic fertilizer. This is ideal for the soil because it can absorb the compost and kill germs easily. A self-propelled compost turner accomplishes its job faster with a higher success rate than other machines.

Techspecs of Self Propelled Compost Turner M30A

Working dataEquipment specificationUnder working conditionsUnder transportati on conditions
Maximum width of allowable accumulation2.6mRoller diameter720mm
Maximum height of allowable stacking1200mmAllowable ground height difference0-200mm
Roller rotation speed250-305rpmThe width of the inner door of the compost machine2450mm
Rubber track width2×220mmThe height of the inner door1200mm
Fuel tank capacity40LLength of equipment3150mm
Maximum diameter of accumulated particles allowed  250mmThe device width1900mm1450mm
Working longitudinal toss distance2-3mHeight of equipment2200mm2000mm
Maximum processing capacity600m³Maximum surface pressure0.5kg/c㎡
Turning radius1500mmWalking speed0-10m/min
Engine data
brandYunnei brand engine
The number of Oil cylinder4
The battery24v
Engine power55KW

Spray device, remote control, power part optional engine brands

 (China Yuchai engine, Japan Yangma engine, The United States Cummins engine)
